"HANDS-FREE" KIT Nr 1 - RECORD & FILM (Parabolic microphone case)

This Kit No. 1 "Hands-free" offered by Chiff-Chaff/Jama/Dodotronic includes the elements described below:

1 suitcase containing:

1 parabolic microphone (with its reflector)
1 integrated hot shoe to attach it to your camera (in the place dedicated to the flash)
1 fixing handle to hold it in hand
Featured Photos: Scroll through the images in our slideshow above.

Total weight: 500g

-----------------------------------------

Instructions for use in brief:

Summary :

In this kit only the parabolic microphone and the above items.

Camera, external recorder, headphones, tripod not included.

Operation with a camera:

Fixing the microphone with the “flash” shoe.

To use the microphone in this Kit only with your camera, check that it has 1 “MIC” microphone input, normally yes.

Without camera:

If you want to use this kit in standalone mode, that is to say WITHOUT a camera, you must use the handle to hold your microphone and it is necessary to have an audio recorder to be able to connect the microphone.

-----------------------------------------

Professional Stereo Parabolic Microphone HI-SOUND COMPACT / DODOTRONIC:

To check compatibility with your equipment, you need to check if you have a 3.5 mm diameter round jack for the headphone input of your camera on the left side. This is often the case in modern cameras.

Features :

diameter: 9.7mm
height: 5mm
sensitivity -24dB
signal to noise ratio 80dB
real performance from 20 Hz to 20 kHz
delivered with a 3.5 mm jack (to be plugged into the external microphone socket of the photo body or camera.)
delivered with a suitcase
delivered with a wind shield
Comes with a handle, useful if you want to use it with an audio recorder instead of a camera.
Sensors:

Sensitivity (1 kHz @ 50cm) 0 db =1V/Pa: -24+3 dB
Rated voltage: 3 VDC
output impedance: 2.2 kΩ
current consumption (3VS with 2.2 kΩ RL): 500 au
signal-to-noise ratio (1kHz, 94 dB input, A-weighted): 80dB
decreasing voltage (3VS to 2VS): -3 dB
frequency range: 20 - 20,000 Hz
Operating voltage range: 1-10 VDC
Max SPL input input (thd<3%): 110 dB
directivity: omnidirectional
Weight: 500g

Warranty: 1 year

----------------------------------
