"HANDS-FREE" KIT Nr 2 - RECORD & FILM (Parabolic microphone case + headset)

This Nr 2 “Hands-free” kit offered by Chiff-Chaff/Jama/Dodotronic includes the elements described below:

1 suitcase containing:

1 parabolic microphone (with its reflector)
1 integrated hot shoe to attach it to your camera (in the place dedicated to the flash)
1 fixing handle to hold it in hand
+ 1 independent element:

1 helmet
-----------------------------------------

Featured Photos: Scroll through the images in our slideshow above

Total weight: 750g

-----------------------------------------

Instructions for use in brief:

Summary :

In this kit, the parabolic microphone and its elements + headphones.

Camera, external recorder, tripod not included.

With a camera:

Fixing the microphone with the “flash” shoe.

To use the microphone and headphones in this Kit only with your camera, check that it has 1 "MIC" microphone input (normally yes) and 1 output for the headphones (not always on certain models).

Without camera:

If you want to use this kit in standalone mode, that is to say WITHOUT a camera, you must use the microphone with its handle and it is necessary to have an audio recorder to be able to connect the microphone on the one hand, and the helmet on the other hand.

-----------------------------------------

1. HI-SOUND COMPACT / DODOTRONIC pro Stereo Parabolic Microphone:

To check compatibility with your equipment, you need to check if you have a 3.5 mm diameter round jack for the headphone input of your camera on the left side. This is often the case in modern cameras.

Features :

diameter: 9.7mm
height: 5mm
sensitivity -24dB
signal to noise ratio 80dB
real performance from 20 Hz to 20 kHz
delivered with a 3.5 mm jack (to be plugged into the external microphone socket of the photo body or camera.)
delivered with a suitcase
delivered with a wind shield
Comes with a handle, useful if you want to use it with an audio recorder instead of a camera.
Sensors:

Sensitivity (1 kHz @ 50cm) 0 db =1V/Pa: -24+3 dB
Rated voltage: 3 VDC
output impedance: 2.2 kΩ
current consumption (3VS with 2.2 kΩ RL): 500 au
signal-to-noise ratio (1kHz, 94 dB input, A-weighted): 80dB
decreasing voltage (3VS to 2VS): -3 dB
frequency range: 20 - 20,000 Hz
Operating voltage range: 1-10 VDC
Max SPL input input (thd<3%): 110 dB
directivity: omnidirectional
Weight: 500g

Warranty: 1 year

2. SONY Headphones - MDR-ZX310 STEREO HEADPHONES:

With an ergonomic ear-friendly design, the headphones can naturally adapt to the angle of all ear shapes, without compressing the ear.

Weight: 250g

Note: Non-contractual photos. This item can be exchanged with a helmet from another brand with the same or better characteristics if the manufacturer has upgraded it.

----------------------------------
